0.42 Inch Monochrome OLED Display 72X40 Resolution Small OLED Display Panel
| MOQ: | 10pcs |
| Price: | Negotiable |
| Standard Packaging: | Cartons, Capboard, EPE, Blister Tray. |
| Delivery Period: | 3-5days |
| Payment Method: | T/T, Paypal |
| Supply Capacity: | 7kk/M |
0.42 Inch Monochrome OLED Display
,0.42 Inch OLED Display Panel
,Small OLED Display Panel
0.42 Inch Mini OLED Display Monochrome 72X40 Resolution Small OLED Display Panel
LIMITO OLED Description:
QG-7240TSWDG01 OLED Display Module is a 72x40 resolution COG graphic display, with a diagonal size of 0.42 inch. The OLED model is designed as an industrial-grade product, offering the advantage of a competitive price. The module is built with ST7315 IC; it supports I2C and a 4-wire SPI serial interface. The supply voltage for logic is 2.8V, supply voltage for display is 9V, Operating Current for VDD is 180μA, driving duty 1/40.
LIMITO OLED specification:
| Part Name: | OLED Display Module |
| Limito Part ID: | QG-7240TSWDG01 |
| Display Mode: | Passive Matrix |
| Display Color: | Monochrome (White) |
| Drive Duty: | 1/40 Duty |
| Number of Pixels: | 72*40 |
| Panel Size: | 12*11*1.25 (mm) |
| Active Area: | 9.196*5.18 (mm) |
| Pixel Pitch: | 0.128*0.13 (mm) |
| Pixel Size: | 0.108*0.11(mm) |
LIMITO OLED Mechanical Drawing
LIMITO is OLED Display module supplier,it’s a market leader and pioneer in OLED solutions which include Transparent OLED,Flexible OLED,Monochrome OLED,Character OLED,Segment OLED,Area Color OLED, Full color OLED,Customizedized design products ect.
LIMITO OLED Benefits:
High Contrast Ration(10,000:1)
Free Viewing Angle
Fast Response Time(<15us)
Thinner & Lighter & Durable
Wide operation Temperature-40°c~+85°c
Self-emitting, no need for a backlight
LIMITO OLED Application:
Industrial: Mearusring& meter, OA Equipment, POS & Server Card Reader, Door Security, USB Key
Communication: Mobile Phone, Bluetooth Device, Router, Set-Top Box
Automotive: Head Up display, Car Audio, Speed Detector, ECT, Timer, Climate Control, Dashboard
PC peripheral: Keyboard, Mouse, Printer, Scanner, NAS, Digital Pen
Medical: Glucose Meter, Oximeter, Blood-pressure Meter, Beauty & Cosmetic Equipment
Consumer: IoT, E-Cigarette, Wearable Device, Remote Controller, Game Machine, Digital Camera, Audio Video Equipment
